Atlas Aluminum Flagpole - External Halyard
This external halyard flagpole offers a balance of economy, strength and quality.
- 100% MADE IN THE USA - Not just assembled in the USA but manufactured here, too.
- STRAIGHTFORWARD SHIPPING FEES - $9 flat rate shipping.
- WARRANTY - Lifetime warranty on the flagpole shaft is included with your purchase. See warranty statement for complete details.
- PLEASE NOTE - Flag is NOT included.
DETERMINE WHICH FLAGPOLE MODEL TO ORDER
*Use the specifications below to determine which flagpole model will best meet your technical needs. Flagpoles 40' or less can be ordered online. Otherwise, please call us to get pricing or to place an order. Our phone number is 877-233-0608.
| SPECIFICATIONS - Atlas Flagpoles | ||||||||||
| SKU | EXPOSED HEIGHT | OVERALL LENGTH | UNFLAGGED MAX. WIND SPEED | FLAGGED MAX. WIND SPEED | SUGGESTED FLAG SIZE | # OF SECTIONS | BUTT DIAMETER | TOP DIAMETER | WALL THICKNESS | SHIPPING WEIGHT |
| ECSA20 | 20' | 22' | 152 mph | 110 mph | 3' x 5' | 1 | 4" | 2-3/8" | 0.125 | 92 lbs. |
| ECSA25 | 25' | 27' | 113 mph | 88 mph | 4' x 6' | 1 | 4" | 2-3/8" | 0.125 | 112 lbs. |
| ECXA25 | 25' | 27' | 183 mph | 120 mph | 4' x 6' | 1 | 5" | 3" | 0.156 | 147 lbs. |
| ECXA30 | 30' | 33' | 119 mph | 95 mph | 5' x 8' | 1 | 5" | 3" | 0.156 | 162 lbs. |
| ECL30 | 30' | 33' | 131 mph | 100 mph | 5' x 8' | 1 | 5" | 3" | 0.188 | 180 lbs. |
| ECA30 | 30' | 33' | 184 mph | 115 mph | 5' x 8' | 1 | 6" | 3-1/2" | 0.156 | 218 lbs. |
| ECSA35 | 35' | 38-1/2' | 104 mph | 86 mph | 6' x 10' | 1 | 5" | 3" | 0.188 | 228 lbs. |
| ECA35 | 35' | 38-1/2' | 175 mph | 114 mph | 6' x 10' | 1 | 7" | 3-1/2" | 0.156 | 251 lbs. |
| ECA40 | 40' | 44' | 171 mph | 110 mph | 8' x 12' | 2 | 8" | 3-1/2" | 0.156 | 298 lbs. |
| ECXA60* | 60' | 66' | 150 mph | 106 mph | 12' x 18' | 3 | 10" | 4" | 0.250 | 754 lbs. |
PICK A FINISH FOR YOUR FLAGPOLE
Unless noted otherwise, all finishes are anodized. (Anodizing is an electrochemical process that gives metal a more durable and corrosion-resistant finish.)
- Satin (not anodized)
- Clear
- Dark Bronze
- Black
SHIPMENT DETAILS
IMPORTANT: If your new flagpole will not be installed immediately upon delivery, be sure to store it in a dry location. If the outer tube and/or the wrappings get damp or wet, remove the tube and protective wrapping and place the unwrapped flagpole and parts at least 12” above grade. If this is not done, mold will develop and ruin the finish of the flagpole. The factory cannot assume responsibility for improperly stored flagpoles.
INCLUDED WITH YOUR SHIPMENT
- Flagpole
- Gold anodized aluminum ball ornament
- Cast aluminum revolving truck with pulley (except for ECSA20 and ECSA25 flagpoles, which have a stationary truck as standard)
- Solid braided polypropylene halyard
- Swivel flag snaps with vinyl snap covers
- Cast aluminum cleat with mounting screws
- Metal swivel flag snaps with vinyl covers
- Spun aluminum flash collar
- Galvanized steel foundation sleeve
DO YOU HAVE QUESTIONS?
At Flags For Veterans, we've been selling flags and flag accessories for over thirty years;
If you have a question, we probably have an answer.
Give us a call at 877-233-0608.
